Dual LP4 / LP6 LED Auxiliary Light Kit for Jeep JL / JT with Steel Bumpers

This Baja Designs lighting and wiring setup has been tested on the Jeep JL / JT with the Rubicon Steel bumper to take the guess work out of installation!

Features:

• Satisfactions Guarantee – 30 Day Money BackGuarantee

• Limited Lifetime Warranty – Complete Purchase Protection

• uService® – Replaceable Lenses And Optics

• ClearView® – All The Light, Right Where You Need It.

• MoistureBlock™ – Waterproof, Rain Proof, Submersible

• CopperDrive® – Only LED Driven At 100%

• 5000K Daylight – Less Driver Fatigue, Natural Color

Applications: Jeep 2020-24 Gladiator, 2018-24 Wrangler JL, NOTE: w/ OE steel bumper

LP4 Auxiliary Light Kit

This lighting and wiring setup has been tested on the Jeep JL / JT with the Rubicon Steel bumper to take the guess work out of installation! The LP4 is the smallest variant in the LP line up but maintains all of the power and features of its siblings. The wiring in this kit is specifically designed to run in conjunction with factory upfitter systems or sPOD / Switch Pros units (447672UP only). The LP4 features a total of 8,750 lumens and a 200° spread of useable LED light. This light pumps out 7,050 forward projecting lumens and 1,700 lumens of dedicated peripheral lighting courtesy of our patented Integrated Peripheral Technology (IPT).

To keep your light performing at its highest potential, the LP4 integrates proprietary Direct Ducted Cooling (DDC) technology. This feature allows air to travel through the front of the housing, over the rear heat sinks - drastically improving cooling capacity and performance.

With an amber day-time running light, the LP4 will fulfill all your lighting needs.

Specifications:

• Forward Projecting Lumens: 7,050 Utilizing 4 LEDs

• Forward Projecting Wattage/Amps: 60W / 6.5A

• IPT Lumens: 1,700 Utilizing 4 LEDs

• IPT Wattage/Amps: 15W / 1.0A

• Backlight Wattage/Amps: 4.83W / 0.35A

• Dimensions: 5.1" Height / 5.1" Width / 3.2" Depth

• Weight: 2.8lbs

• LED Life Expectancy: 49,930 Hours

• Front Lens: Hardcoated Polycarbonate

• Housing: Hard Anodized Machined Aluminum

• Bezel: Billet Machined Aluminum

• Hardware & Bracket Material: Stainless Steel

• Exceeds MIL-STD810G (Mil-Spec Testing)

• Built-In Overvoltage Protection

• IP69K (Waterproof up to 9ft & Pressure Washable)

• IK10 Compliant (Mechanical Impact Testing)

Includes:

• QTY (2) LP4 LED Light
• QTY (1) Wiring Harness (447672 only)
• QTY (2) Upfitter (447672UP only)
• Zip ties

Patterns:

• Driving/Combo: Maximum trail coverage in a single light.  The Driving/Combo pattern is equipped with both Wide Driving (42°) and the spot (6°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)

LP6 Auxiliary Light Kit

This lighting and wiring setup has been tested on the Jeep JL / JT with the steel bumper to take the guess work out of installation! The wiring in this kit is specifically designed to run in conjunction with factory upfitter systems or sPOD / Switch Pros units (447671UP only). The LP6 Pro is a 6-inch powerhouse featuring a total of 10,300 lumens and a 200° spread of useable LED light. The LP6 features 8,600 forward projecting lumens and 1,700 lumens of dedicated peripheral lighting courtesy of patented Integrated Peripheral Technology (IPT).

To keep your light performing at its highest potential, the LP6 integrates our proprietary Direct Ducted Cooling (DDC) technology. This feature allows air to travel through the front of the housing, over the rear heat sinks - drastically improving cooling capacity and performance.

With an amber day-time running light, low power, and high power mode, the LP6 will fulfill all your lighting needs.

Specifications:

• Forward Projecting Lumens: 8,600 Utilizing 6 LEDs

• Forward Projecting Wattage/Amps: 90W / 6.5A

• IPT Lumens: 1,700 Utilizing 4 LEDs

• IPT Wattage/Amps: 15W / 1.0A

• Backlight Wattage/Amps: 4.14W / 0.3A

• Dimensions: 6.5" Height / 6.5" Width / 3.2" Depth

• Weight: 4.2lbs

• LED Life Expectancy: 49,930 Hours

• Front Lens: Hardcoated Polycarbonate

• Housing: Hard Anodized Machined Aluminum

• Bezel: Billet Machined Aluminum

• Hardware & Bracket Material: Stainless Steel

• Exceeds MIL-STD810G (Mil-Spec Testing)

• Built-In Overvoltage Protection

• IP69K (Waterproof up to 9ft & Pressure Washable)
• IK10 Compliant (Mechanical Impact Testing)

Inlcudes:

• QTY (2) LP6 LED Light
• QTY (1) Wiring Harness (447671 only)
• QTY (2) Upfitters (447671UP only)
• Zip ties

Patterns:

• Driving/Combo: Maximum trail coverage in a single light.  The Driving/Combo pattern is equipped with both Wide Driving (42°) and the spot (6°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)
